Motorized Spring Testing Machine
185000 INR/Unit
Product Details:
- Color Blue
- Operate Method Manual
- Material Alloy Steel
- Voltage 180 V/AC to 260 V/AC Volt (v)
- Usage Industrial
- Click to View more
X
Motorized Spring Testing Machine Price And Quantity
- 1 Unit
- 185000 INR/Unit
Motorized Spring Testing Machine Product Specifications
- 180 V/AC to 260 V/AC Volt (v)
- Industrial
- Manual
- Alloy Steel
- Blue
Motorized Spring Testing Machine Trade Information
- 1000 Unit Per Month
- 2-10 Days
- All India
Product Description
The Motorized Spring Testing Machine by SIMSU is a digital testing machine suitable for industrial use. Its sturdy construction with alloy steel material ensures durability and longevity. This machine operates manually and has a voltage requirement of 180 V/AC to 260 V/AC. The machine has a maximum deflection/displacement of 750mm and a maximum diameter and length of the spring at 250mm and 750mm, respectively. The load application is through a speed-controlled motorized system, and the load measurement is done through a load cell. The machine is equipped with a microcontroller-based LCD digital display unit that displays force and deflection. It also has a peak hold facility and an overload alarm that buzzes on overload. The machine comes with a 1-year warranty and has a capacity of 1000Kgf.
| Deflection/Displacement | 750 mm (Maximum) |
| Diameter of Spring | 250 mm (Maximum) |
| Digital Indicator | Microcontroller based LCD Digital Display Unit. |
| Display (Force & Deflection) | LCD Display |
| Length of Spring | 750 mm (Maximum) |
| Load Applying | Through Speed Controlled Motorized |
| Load Measurement | By Load Cell |
| Machine Mounting | Floor Mount |
| Mode of Operation | Compression |
| Overload Alarm | Buzzer on overload |
| Peak Hold Facility | Yes |
| Type | Digital |
| Warranty | 1 Year |
| Country of Origin | Made in India |
| Speed | 10 mm/min to 100 mm/min |
| Power Source | 180 V/AC to 260 V/AC @50 Hz |
| Material | Alloy Steel |
| Least Count | 0.1 Kgf |
| Capacity | 1000 Kgf |
| Accuracy | +- 0.5% of the reading |
| Brand | SIMSU |
FAQs of Motorized Spring Testing Machine:
Q: What is the maximum deflection/displacement of the machine?
A: The machine has a maximum deflection/displacement of 750mm.Q: What is the capacity of the machine?
A: The machine has a capacity of 1000Kgf.Q: What is the warranty period of the machine?
A: The machine comes with a 1-year warranty.Q: What is the mode of operation of the machine?
A: The machine operates in compression mode.Q: What is the accuracy of the machine?
A: The accuracy of the machine is +- 0.5% of the reading.Enter Buying Requirement Details
